750KVA-1000KVA Three Phase Pad Mounted Transformer Oil Cooling Step Up Operation
750KVA-1000KVA Three Phase Pad Mounted Transformer Oil Cooling Step Up Operation Product Specifications Attribute Value Frequency 50Hz, 60Hz, 50/60 Hz Application Distribution System Output Voltage 380V, 400V, 440V, 480V Input Voltage 10kV Product Name Three Phase Oil Immersed Transformer Rated ...
1000KVA Three Phase Pad Mounted Transformer
,750KVA Pad Mounted Transformer Oil Cooling
,Step Up Operation Pad Mounted Transformer
| Attribute | Value |
|---|---|
| Frequency | 50Hz, 60Hz, 50/60 Hz |
| Application | Distribution System |
| Output Voltage | 380V, 400V, 440V, 480V |
| Input Voltage | 10kV |
| Product Name | Three Phase Oil Immersed Transformer |
| Rated Capacity | 750KVA-1000KVA |
| Cooling Method | Oil Cooling |
| Impedance | 5.8% |
| Standard | ANSI / IEEE / DOE 2016 |
| Enclosure Rating | NEMA 3R or NEMA 4X |
| UL Certificate Numbers | UL-US-2431836-0, UL-CA-2423202-0 |
| Secondary Voltage | 120/240 V or 208Y/120 V |
| Temperature Rise | 65°C |
| Operation | Step-Up Operation |
| Transformer Feed Type | Loop Feed |
| Capacity (KVA) | HV | Tapping Range | LV | No-load Loss | Load Loss | Impedance | Efficiency |
|---|---|---|---|---|---|---|---|
| 75 | 2400 4160 7200 7620 12000 12470 13200 13800 14400 19920 24940 34500 | ±2X2.5% | 110 120 208 240 277 347 415 416 480 600 690 | 130 | 100 | 4.0-6.3 | 99.03 |
| 750 | 880 | 7500 | 99.4 | ||||
| 1000 | 1000 | 10300 | 99.43 |
- Three-phase, pad-mounted configuration
- Oil-immersed for efficient cooling
- Fully enclosed, tamper-resistant construction
- Outdoor-rated, weatherproof design
- Quiet and low-vibration operation
- Long service life with minimal maintenance
- Compliant with ANSI, IEEE, IEC standards
- High Power Delivery: Supports large-scale operations with stable, balanced power distribution.
- Outdoor Resilience: Withstands extreme temperatures and moisture, ideal for exposed or remote locations.
- Maintenance-Friendly: Sealed design minimizes the need for routine servicing, saving time and cost.
- Space-Saving Installation: Pad-mounted configuration allows quick setup in confined or urban spaces.
- Enhanced Safety: Built-in tamper protection and thermal safety features ensure operational security.
- Energy Efficient: Optimized design reduces energy losses and improves long-term cost savings.
- Flexible Deployment: Suitable for both new installations and upgrades in commercial, industrial, or utility settings.
- Industrial Zones: Reliable power for heavy equipment and factory operations.
- Commercial Developments: Powers shopping malls, data centers, and large buildings.
- Utility Substations: Part of grid expansion or backup systems.
- Renewable Energy Integration: Converts and stabilizes output from solar and wind farms.
- Municipal Infrastructure: Used in street lighting networks, public facilities, and transportation hubs.
-
