Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv

Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv

Pole Mounted Distribution Transformer 15kva

Single Phase Distribution Transformer 37.5kva

Place of Origin:

Jiangsu, China

Brand Name:

HENTG Power

Certification:

CE

Model Number:

S11

Chat Now
Request A Quote
Product Details
Frequency:
60Hz
Phase:
Single Phase
Application:
Power Transformer
Output Voltage:
110V, 220V, 380V, 400V , 440V, 480V
Input Voltage:
11kV, 10.5kV, 3kV, 6.6kV, 6.3kV, 35kV, 12.47kV, 6kV
Product Name:
Single Phase Pole Mounted Transformer
Rated Capacity:
10KVA-500KVA
High Voltage:
11kv 10kv 6.3kv 6kv
Low Voltage:
120-240/240-480/347/600V
Application:
Power Distribution System Power Transformer
Standard:
DOE/IEC60076/IEEE
Vector Group:
Dyn11 / Yyn0
Cooling Method:
ONAN
Warranty:
2 Years
MOQ:
1 Unit
Highlight:

Pole Mounted Distribution Transformer 15kva

,

Single Phase Distribution Transformer 37.5kva

Payment & Shipping Terms
Minimum Order Quantity
2 sets
Price
CN¥17,806.25/sets 2-999 sets
Product Description
Single Phase Pole Mounted Distribution Transformer 15kVA - 500kVA
Product Specifications
Attribute Value
Frequency 60Hz
Phase Single Phase
Application Power Transformer
Output Voltage 110V, 220V, 380V, 400V, 440V, 480V
Input Voltage 11kV, 10.5kV, 3kV, 6.6kV, 6.3kV, 35kV, 12.47kV, 6kV
Rated Capacity 10KVA-500KVA
High Voltage 11kV, 10kV, 6.3kV, 6kV
Low Voltage 120-240/240-480/347/600V
Standard DOE/IEC60076/IEEE
Vector Group Dyn11 / Yyn0
Cooling Method ONAN
Warranty 2 Years
MOQ 1 Unit
Product Overview

HENTG Power single-phase pole mounted distribution transformers (15kVA - 500kVA) feature a compact design suitable for installation in various locations while delivering reliable power distribution performance.

Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 0 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 1
Technical Specifications
Capacity (kVA) HV Tapping Range LV No-load Loss (W) Load Loss (W) Dimension (mm) Efficiency
15 2400-34500V ±2*2.5% 110-690V 60-150 330-1150 520×565×905 98.82%
25 98.95%
37.5 99.05%
50 99.11%
75 99.19%
100 99.25%
167 99.33%
250 99.39%
333 99.43%
500 99.49%
Key Advantages
1. Reduced Line Losses and Improved Power Supply Efficiency
  • Installed close to the load, these transformers shorten the low-voltage supply radius
  • Low-voltage line losses are reduced by over 99%, greatly enhancing energy utilization efficiency
2. Efficient and Energy-Saving Structural Design
  • Features a high-efficiency, energy-saving wound core design
  • Compact and lightweight, making installation and transportation easier
3. Flexible Installation
  • Pole-mounted suspension installation requires no ground space
  • Ideal for rural and suburban areas
4. Cost-Effective Solution
  • Requires low capital investment compared to traditional transformer systems
  • Ideal for large-scale deployment
5. High Reliability and Easy Maintenance
  • Fully enclosed structure offers excellent protection against dust and moisture
  • Strong overload capacity ensures stable operation during temporary load surges
  • Easy to maintain, reducing operational costs
Ordering Process
Step 1: Consultation & Quotation

We respond to inquiries within 1 hour with suitable transformer recommendations, reasonable quotations, and payment terms. Our technical team will confirm all drawing details within 7 days after payment.

Step 2: Production & Quality Assurance

After finalizing production drawings, we prepare stock, manufacture, and conduct rigorous quality inspections. We provide QC reports and test reports for all products.

Step 3: Installation & Support

We provide professional installation guidance and support on-site installation when needed. All products come with a 2-year warranty.

Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 2 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 3 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 4 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 5 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 6 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 7 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 8 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 9 Single Phase Pole Mounted Distribution Transformer 15kva 25kva 16Kva 37.5kva 50kva 7.62kv 15kv 10
About HENTG POWER

Global power system solution expert founded in 2011, covering an area of 100,000㎡. We specialize in designing, manufacturing and installing complete power systems.

Quality Assurance
  • Double quality inspection process: pre-production sample confirmation + final inspection
  • Authoritative certification: QC reports, test reports, and FAT (factory acceptance test) support
  • Manufacturing capabilities include oil-immersed/dry-type transformers up to 500KV/480MVA
  • Compliance with ANSI/IEEE/DOE2016/CSA/IEC60076 standards
  • 2+ years warranty on all products
Contact us today for more information or to request a quotation
