400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution

400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution

200kVA 3 Phase Dry Type Transformer

3 Phase Dry Type Transformer Low Loss

Indoor Power Distribution Dry Transformer

Place of Origin:

China

Brand Name:

HENTG Power

Certification:

CE

Model Number:

SCB13

Chat Now
Request A Quote
400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution
400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution 400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution 400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution
Product Details
Frequency:
60Hz, 50Hz, 50/60Hz
Phase:
Three
Application:
Distribution System
Output Voltage:
400V
Input Voltage:
10kV
Type:
Dry Type Transformer, Cast Resin Dry
Product Name:
Dry Type Transformer
Application:
Power Distribution System Power Transformer
Rated Capacity:
200KVA
Material:
Copper Winding
Highlight:

200kVA 3 Phase Dry Type Transformer

,

3 Phase Dry Type Transformer Low Loss

,

Indoor Power Distribution Dry Transformer

Payment & Shipping Terms
Minimum Order Quantity
1
RELATED PRODUCTS
Good price 50Hz Medium Voltage Dry Type Transformer 30KVA Step Up Down Instrument Transformer online Video

50Hz Medium Voltage Dry Type Transformer 30KVA Step Up Down Instrument Transformer

Chat Now
Good price 3 Phase Power Transformer 800KVA 1000KVA 1250KVA Dry Type Step Up Transformer online Video

3 Phase Power Transformer 800KVA 1000KVA 1250KVA Dry Type Step Up Transformer

Chat Now
Good price Commercial Industrial 160kVA Dry Type Transformer Customized Logo For Power Distribution online Video

Commercial Industrial 160kVA Dry Type Transformer Customized Logo For Power Distribution

Chat Now
Good price MV HV Electrical Dry Type Distribution Transformer Three Phase 160kva 200kva 250kva online Video

MV HV Electrical Dry Type Distribution Transformer Three Phase 160kva 200kva 250kva

Chat Now
Contact Us
+86 15074989773
info@hentgpower.com
Chat Now
Product Description
400Volt 200kVA 3 Phase Dry Type Transformer Low Loss Indoor Power Distribution Solution
Product Specifications
Attribute Value
Frequency 60Hz, 50Hz, 50/60Hz
Phase Three
Application Distribution System
Output Voltage 400V
Input Voltage 10kV
Type Dry Type Transformer, Cast Resin Dry
Rated Capacity 200KVA
Material Copper Winding
Technical Specifications
Rated Capacity (KVA) Vector Group Voltage Combination No-load loss Load loss No-load current Impedance
200 Yyn0 / Dyn11 10 6.3 6 ±5% ±2X2.5% (+3/-1)X2.5% 445 2270 1.1 4.0
Product Overview
The SCB13 Series 200kVA Dry-Type Transformer is designed to deliver safe, reliable, and energy-efficient power distribution for medium-sized commercial and industrial applications. Featuring a cast resin insulation system, low-loss silicon steel core, and fire-retardant construction, this transformer ensures excellent thermal performance, minimal maintenance, and outstanding safety for indoor installations such as shopping malls, hospitals, schools, and office buildings.
Key Features
  • 200kVA Rated Capacity: Ideal for medium-scale power distribution applications.
  • Cast Resin Insulation: Flame-retardant and self-extinguishing epoxy for enhanced safety.
  • High-Efficiency Core: Uses high-grade cold-rolled silicon steel to reduce iron losses.
  • Air Natural Cooling (AN): Oil-free design with natural ventilation for silent operation.
  • Moisture-Resistant: Suitable for high-humidity environments without special enclosures.
  • Low Electromagnetic Interference (EMI): Ensures minimal impact on surrounding electronics.
  • Indoor Installation Ready: Compact footprint fits tight mechanical rooms or basements.
Operational Benefits
  • Lower Operating Costs: Reduced core and load losses help cut long-term energy expenses.
  • No Risk of Oil Leaks or Fires: Fully dry design is environmentally safe and code-compliant.
  • Long Service Life: Durable insulation and core design reduce wear over time.
  • Minimal Maintenance Required: No oil filtration, no cooling fans, no complex inspections.
  • Silent Operation: Noise levels suitable for hospitals, schools, and office zones.
  • Flexible Voltage Customization: Supports various primary and secondary voltage configurations.
Additional Advantages
  • Built for Safety-Critical Spaces: Ideal for areas with strict fire safety and emission standards.
  • High Reliability: Withstands overloads and fluctuating environments without failure.
  • Standards-Compliant: Manufactured to IEC 60076 and GB/T 10228 specifications.
  • Eco-Friendly Design: Uses non-toxic insulation materials and produces zero emissions.
  • Custom-Built Options Available: Add IP23/IP44 enclosures or integrate with smart monitoring.
Typical Applications
  • Hospitals and Healthcare Facilities: Stable, clean power for life-saving equipment.
  • Educational Institutions: Safe, quiet performance ideal for schools and universities.
  • Shopping Centers: Supports lighting, HVAC, and escalator systems.
  • Office Buildings: Power delivery for computers, servers, elevators, and lighting.
  • Manufacturing Plants: Reliable source for control panels, machinery, and automation systems.
Frequently Asked Questions
Who are we?
HENTG POWER is a professional designer, manufacturer and installer of power system solutions around the World, founded in 2011, occupying 100,000 square meters. We specialize in reliable, high-performance solutions for global power systems.
How can we guarantee quality?
We always provide a pre-production sample before mass production and conduct final inspection before shipment, including QC & test reports. We accept FAT (Factory Acceptance Test). Our factory can manufacture oil type and dry type distribution transformers, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standard. We provide a guarantee service of over 2 years.
Why choose us?
We have a professional and independent drawing team and technical team, capable of confirming all drawing contents with you within 7 days. Our technical team includes 30+ senior engineers offering 24-hour online service with responses within 30 minutes.
What services can we provide?
We accept OEM, and business payment terms are negotiable.
