Quality Pole Mounted Step Up Variable Voltage Transformer Single Phase ANSI IEEE DOE Approved factory

Pole Mounted Step Up Variable Voltage Transformer Single Phase ANSI IEEE DOE Approved

Product Summary

Pole Mounted Step Up Variable Voltage Transformer Single Phase ANSI IEEE DOE Approved Product Specifications Type Distribution transformer, Oil-IMMERSED Transformer Material Aluminum, Copper Frequency 50Hz, 60Hz Shape ROUND Winding Material Copper Application Power Phase Single Phase Coil Structure ...

Key Attributes

Brand Name: HENTG Power

Model Number: D11

Place of Origin: China

Certification: CE/UL/CSA/IEEE

MOQ: 1

Product Custom Attributes

Highlight

Step Up Variable Voltage Transformer

50 Kva Pole Mounted Variable Voltage Transformer

DOE Approved Variable Voltage Transformer

Type:

Distribution Transformer, Oil-IMMERSED Transformer

Material:

Aluminum, Copper

Frequency:

50Hz, 60Hz

Shape:

ROUND

Winding Material:

Copper

Application:

Power

Phase:

Single Phase

Coil Structure:

Circular Coil

Coil Number:

Dual-winding Coil

Input Voltage:

3kV, 6kV, 10kV, 15kV

Output Voltage:

400V , 208V, 200V, 415V, 127V, 11kV, 380V, 440V, 480V

Product Name:

Oil Distribution Transformer

Application:

Power Distribution System

Standard:

ANSI

Usage:

New Energy

Color:

White

Warranty:

3 Years

Vector Group:

II0/II6

Core Material:

Copper

Model:

PT-100

Mounting Type:

Pole Mounted

Efficiency:

98%

Insulation Class:

Class A

Cooling Method:

ONAN

Protection Level:

IP54

Enclosure Material:

Steel

Rated Power:

100 KVA

Product Description

Pole Mounted Step Up Variable Voltage Transformer Single Phase ANSI IEEE DOE Approved

Product Specifications

Type	Distribution transformer, Oil-IMMERSED Transformer
Material	Aluminum, Copper
Frequency	50Hz, 60Hz
Shape	ROUND
Winding Material	Copper
Application	Power
Phase	Single Phase
Coil Structure	Circular coil
Coil Number	Dual-winding coil
Input Voltage	3kV, 6kV, 10kV, 15kV,
Output Voltage	400V, 208V, 200V, 415V, 127V, 11kV, 380V, 440V, 480V
Standard	ANSI
Usage	New Energy
Warranty	3 Years
Vector Group	II0/II6
Core Material	Copper
Model	PT-100
Mounting Type	Pole Mounted
Efficiency	98%
Insulation Class	Class A
Cooling Method	ONAN
Protection Level	IP54

Product Description

HENTG POWER Mv Hv Oil Immersed Transformer Variable Voltage Transformer 50 Kva Pole Mounted Single Phase Step up Transformer

✓ Full series of transformers (oil-immersed/dry type/500KV level)

✓ One-stop delivery of GIS/switchgear/substation

✓ International endorsement: 100% compliant with 5 major standards such as ANSI/IEEE/DOE

✓ Long-term service: more than 2 years of warranty coverage

Unique Value Proposition

Extremely fast technical response: Professional design team can lock drawing details within 7 days
30+ senior engineers available 24 hours online with 30-minute emergency response time
