Oil Cooling Single Phase Pole Mounted Transformer 25Kva To 100Kva Wound Core Design
Oil Cooling Single Phase Pole Mounted Transformer 25Kva To 100Kva Wound Core Design Product Specifications Attribute Value Type Power transformer, Oil-filled Transformer Material Aluminum, Aluminum Winding Frequency 50Hz, 60Hz Shape ROUND, Coil Topology BUCK Winding Material Aluminum Application Power Phase Single Phase Coil Structure Wound Coil Coil Number Dual-winding coil Input Voltage 180V, 115V, 3kV, 6kV, 10kV, 15kV, 35kV, 69kV Output Voltage 400V, 5V, 208V, 200V, 415V,
Wound Core Pole Mounted Transformer 25Kva
,Oil Cooling Pole Mounted Transformer 100Kva
| Attribute | Value |
|---|---|
| Type | Power transformer, Oil-filled Transformer |
| Material | Aluminum, Aluminum Winding |
| Frequency | 50Hz, 60Hz |
| Shape | ROUND, Coil |
| Topology | BUCK |
| Winding Material | Aluminum |
| Application | Power |
| Phase | Single Phase |
| Coil Structure | Wound Coil |
| Coil Number | Dual-winding coil |
| Input Voltage | 180V, 115V, 3kV, 6kV, 10kV, 15kV, 35kV, 69kV |
| Output Voltage | 400V, 5V, 208V, 200V, 415V, 127V |
| Rated Capacity | 25-100kva |
| Usage | Power Electronic |
| Warranty | 3 Years |
| Cooling Method | Oil Cooling |
| Rated capacity (KVA) | HV | Tapping range | LV | No-load loss | Load loss | Dimension (mm) | Efficiency |
|---|---|---|---|---|---|---|---|
| 15 | 2400 4160 7200 7620 12000 12470 13200 13800 14400 19920 24940 34500 |
±2*2.5% | 110 120 208 240 277 347 415 416 480 600 690 |
60 80 100 120 130 150 |
330 370 450 620 850 1150 |
520 560 610 635 754 770 795 |
98.8 |
- Reduced Line Losses and Improved Power Supply Efficiency - Installed close to the load, these transformers shorten the low-voltage supply radius, significantly reducing the length of low-voltage lines. Low-voltage line losses are reduced by over 99%, greatly enhancing energy utilization efficiency.
- Efficient and Energy-Saving Structural Design - Features a high-efficiency, energy-saving wound core design, improving electrical performance and energy efficiency. Compact and lightweight, making installation and transportation easier and more adaptable to various environments.
- Flexible Installation - Utilizes a pole-mounted suspension installation, allowing direct mounting on utility poles without occupying ground space -- ideal for rural and suburban areas.
- Cost-Effective - Requires low capital investment compared to traditional transformer systems, making it well-suited for large-scale deployment.
- High Reliability and Easy Maintenance - Built with a fully enclosed structure, offering excellent protection against dust and moisture. Strong overload capacity ensures stable operation during temporary load surges. Highly reliable for continuous operation and easy to maintain, reducing operational and maintenance costs.
- Oil-immersed transformers
- Dry-type power transformers
- SH15 and SCBH15 amorphous alloy transformers
- YB prefabricated substations
- ZGS modular substations
- Transformers for new energy systems
- Custom-engineered specialty transformers
