Name: High Capacity Theree Phase Pad Mounted Transformer 3750kva 50Hz For Power Substation
Brand: Hunan Hentg Power Electric Technology Co., Ltd.
SKU: ZGS Series
Price: 93.00 USD
Availability: InStock

Home > products > Three Phase Pad Mounted Transformer >

High Capacity Theree Phase Pad Mounted Transformer 3750kva 50Hz For Power Substation

Theree Phase Pad Mounted Transformer 3750kva

High Capacity Pad Mounted Transformer

50Hz Pad Mounted Distribution Transformers

Place of Origin:

Jiangsu, China

Brand Name:

HENTG Power

Certification:

Model Number:

ZGS Series

Chat Now

Request A Quote

Product Details

Frequency:

50Hz

Coil Number:

Multi Winding, Three Windings, Two Windings

Application:

Distribution System

Coil Structure:

Shell-Type Coil, Disc Coil, Fully Sealed Construction

Output Voltage:

110V, 220V, 380V, 400V , 440V, 480V

Input Voltage:

11kV, 10.5kV, 3kV, 12.47kV, 6.6kV, 6kV, 10kV, 35kV

Type:

Oil-Immersed Transformer, Loop Feed/ Radial Feed

Efficiency:

>99%

Name:

Oil Type Three Phase Pad Mounted Transformer

Primary Voltage:

2.4 Through 35KV (150KV BIL)

Low Voltage:

Up To 600 Volts

Customized:

Capacity:

3150-3750 KVA

Warranty:

3 Years

Feed Type:

Loop Feed

Connection Group:

DYN1

Enclosure Rating:

NEMA 3R

Application:

Data Center,Utility,New Energy

Mounting:

Pad-Mounted

Impedance:

4.5%

Sound Level:

65dBA

Winding Material:

Copper Or Aluminum

Efficienc:

99.00%

Highlight:

Theree Phase Pad Mounted Transformer 3750kva

High Capacity Pad Mounted Transformer

50Hz Pad Mounted Distribution Transformers

Payment & Shipping Terms

Minimum Order Quantity

2 sets

Price

CN¥62,678-124,643.75/sets

Outdoor Oil Immersed Power Transformer 3 Phase Pad Mounted 750kVA

Chat Now

Video

750kVA Three Phase Oil Filled Pad Mounted Transformer Outdoor Power Solution

Chat Now

Video

Oil Immersed Three Phase Pad Mounted Transformer 225KVA CE Certified ONAN Cooling

Chat Now

Video

Three Phase Pad Mounted Transformer Step Up Step Down 500KVA 750KVA 1000kVA 1500KVA

Chat Now

+86 15074989773

info@hentgpower.com

Chat Now

Product Description

High Capacity Three Phase Pad Mounted Transformer 3750kVA 50Hz For Power Substation

Product Specifications

Attribute	Value
Frequency	50Hz
Coil Number	Multi Winding, Three Windings, Two Windings
Application	Distribution system
Coil Structure	Shell-Type Coil, Disc Coil, fully sealed construction
Output Voltage	110V, 220V, 380V, 400V, 440V, 480V
Input Voltage	11kV, 10.5kV, 3kV, 12.47kV, 6.6kV, 6kV, 10kV, 35kV
Type	Oil-Immersed Transformer, Loop feed/Radial feed
Efficiency	>99%
Primary Voltage	2.4 through 35KV (150KV BIL)
Low Voltage	Up to 600 volts
Capacity	3150-3750 kVA
Warranty	3 years
Connection Group	DYN1
Enclosure Rating	NEMA 3R
Application	Data center, Utility, New energy
Mounting	Pad-Mounted
Impedance	4.5%
Sound Level	65dBA
Winding Material	Copper or Aluminum

Product Overview

High-Capacity Panel Electrical Equipment for Power Substation 3750kVA Three-Phase Pad Mounted Transformer

Technical Parameters

Capacity (KVA)	HV	Tapping range	LV	No-load loss	Load loss	Impedance	Efficiency
75	2400 4160 7200 7620 12000 12470 13200 13800 14400 19920 24940 34500	±2X2.5%	110 120 208 240 277 347 415 416 480 600 690	130	100	4.0-6.3	99.03
152				200	1800		99.16
225				350	3100		99.23
300				430	3700		99.27
500				600	5410		99.35
750				880	7500		99.4
1000				1000	10300		99.43
1500				1400	14500		99.48
2000				1800	18300		99.51
2500				2300	23100		99.53
3150
3750

Key Features & Benefits

Feature: This 3750kVA three-phase pad-mounted transformer adopts advanced cold-rolled silicon steel lamination core technology, ensuring excellent magnetic permeability and low hysteresis loss. The winding material is high-quality aluminum, which effectively reduces eddy current losses and improves overall performance.
Advantage: The robust structural design enables it to withstand harsh weather and external forces, ensuring long-term stable operation. Low operating costs and heat dissipation reduce energy consumption and maintenance costs of cooling equipment.
Benefit: Provides significant energy savings, reducing electricity bills and operating costs. Its efficient and stable performance extends service life, reducing replacement and maintenance frequency, ensuring reliable power supply for industrial, commercial, and public facilities.
