1000 KVA Tap Changer Step Up Step Down Transformer Mv Hv IP54 Protection Pre Installed
1000 KVA Tap Changer Step Up Step Down Transformer MV HV IP54 Protection Pre Installed Product Specifications Attribute Value Type Power transformer, distribution transformer Material Aluminum, Copper Frequency 50Hz, 60Hz Shape Rectangle Winding Material Copper, Aluminum Application Power Phase Three Coil Structure Circular coil Coil Number Multi-winding coil Input Voltage 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 115kV Output Voltage 415V, 127V, 200V, 208V, 400V, 380V, 220V
1000 KVA Tap Changer Transformer
,Step Up Step Down Transformer Mv Hv
| Attribute | Value |
|---|---|
| Type | Power transformer, distribution transformer |
| Material | Aluminum, Copper |
| Frequency | 50Hz, 60Hz |
| Shape | Rectangle |
| Winding Material | Copper, Aluminum |
| Application | Power |
| Phase | Three |
| Coil Structure | Circular coil |
| Coil Number | Multi-winding coil |
| Input Voltage | 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 115kV |
| Output Voltage | 415V, 127V, 200V, 208V, 400V, 380V, 220V |
| Warranty | 3 Years |
| Product Name | Pre-Installed Substation |
| Installation Location | Outdoor |
| Protection Level | IP33D/IP54 |
| Altitude | <1000m (High altitude products can be customized) |
| Customized | Accept |
| Capacity | 50-2000 kVA |
HENTG's pre-installed substations are compact, factory-assembled solutions that integrate transformers, switchgear, and protection systems in a weatherproof enclosure. Designed for quick deployment, easy installation, and minimal on-site work, they are ideal for urban grids, industrial parks, renewable energy plants, and construction sites.
| Item | Unit | Data |
|---|---|---|
| Rated Frequency | Hz | 50 |
| Rated Voltage | kV | 6 10 35 |
| Max Working Voltage | kV | 6.9 11.5 40.5 |
| Industrial Frequency Voltage-resisting Time | kV | 32/36 42/48 95/118 |
| Thunder and Lighting Ballistic Voltage-resisting Time /isolation Sectional Port | kV | 60/70 75/85 185/215 |
| Rated Current | A | 400 630 |
| Rated Brief-period Current-resisting | kA | 12.5(2s) 16(2s) 20(2s) |
| Rated Crest Value Current-resisting | kA | 32.5 40 50 |
| Item | Unit | Data |
|---|---|---|
| Rated Voltage | V | 380 220 |
| Rated Current Of Major Return Circuit | A | 100-3200 |
| Rated short-circuit Current-resisting | kA | 15 30 50 |
| Rated Crest Value Current-resisting | kA | 30 63 110 |
| Branch Circuit | A | 10-800 |
| Quantity Of Branch | line | 1月12日 |
| Compensation Circuit | kVAR | 0-360 |
| Item | Unit | Data |
|---|---|---|
| Rated Capacity | kVA | 50-2000 |
| Short-circuit Impendance | % | 4 6 |
| Scope Of Branch Connection | +2x2.5% ±5% | |
| Vector Group | Yyn0 Dyn11 |
- Aesthetic and Durable Appearance: The unit has a clean and modern appearance, with strong environmental adaptability. It integrates well with surrounding architecture and landscaping, enhancing the overall urban aesthetic.
- Proximity to Medium-Voltage Load Centers: Enables deployment close to medium-voltage load centers, reducing distribution line length, lowering line losses, and improving power quality and supply reliability.
- Cost-Effective and Low Operating Costs: Requires no civil infrastructure, reducing initial investment. No need for fulltime staffing, minimizing labor costs. The long maintenance cycle and easy operation result in a lower total cost of ownership throughout the lifecycle.
- Reusable and Environmentally Friendly: The modular substation can be relocated and reused based on urban development needs, avoiding redundant investments and supporting sustainable development goals.
HENTG POWER is a professional designer, manufacturer and installer of power system solution around the World, was founded in 2011, occupies 100,000 square meter. specializing in reliable, high-performance solutions for global power systems.
Always a pre-production sample before mass production; Always final Inspection before shipment, We will provide QC & test reports. We accept FAT(Factory Acceptance Test). Factory can manufacture oil type and dry type distribution transformer, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standard. We will provide you with the guarantee service of over 2 years.
We have the professional and independent drawing team and technical team, It is expected that we can confirm all the contents on the drawings with you within 7 days. we have a professional technical team with 30+ senior engineers offer 24 hours online service and response within 30 min.
Accept OEM, business payment are negotiated. If you have any questions, welcome to click here for discussion!
-
