Three Phase Substation Oil Immersed Transformer Electrical Mv Voltage Transformer 45kVA-300kVA
Three Phase Oil Immersed Transformer (45kVA-300kVA) Product Specifications Attribute Value Frequency 50Hz, 60Hz Phase Three Coil Number Three Windings, Multi Winding, Two Windings, Single Winding Application Distribution System Coil Structure Shell-Type Coil, layer coil, fully sealed construction, Disc Coil, round coil Output Voltage 10kV, 415V, 110V, 380V, 400V, 440V, 480V, 11kV Input Voltage 10.5kV, 11kV, 12.47kV, 6.6kV, 6.3kV, 6kV, 10kV, 35kV, 69kV, 110kV, 115kV, 132kV
Electrical Substation Oil Immersed Transformer
,Mv Voltage Transformer Compact Substation
| Attribute | Value |
|---|---|
| Frequency | 50Hz, 60Hz |
| Phase | Three |
| Coil Number | Three Windings, Multi Winding, Two Windings, Single Winding |
| Application | Distribution System |
| Coil Structure | Shell-Type Coil, layer coil, fully sealed construction, Disc Coil, round coil |
| Output Voltage | 10kV, 415V, 110V, 380V, 400V, 440V, 480V, 11kV |
| Input Voltage | 10.5kV, 11kV, 12.47kV, 6.6kV, 6.3kV, 6kV, 10kV, 35kV, 69kV, 110kV, 115kV, 132kV |
| Type | Isolation Transformer, Voltage Regulator Transformer, AUTOTRANSFORMER, Field Adjustable Transformer, Oil-Immersed Transformer, Dual Winding Transformer, Compact Substation |
| Rated Capacity | 45KVA-300KVA |
| Vector Group | Dyn11 / Yyn0 |
| Parameter | Unit | Value |
|---|---|---|
| Rated Frequency | Hz | 50 |
| Rated Voltage | kV | 6, 10, 35 |
| Max Working Voltage | kV | 6.9, 11.5, 40.5 |
| Industrial Frequency Voltage-resisting Time | kV | 32/36, 42/48, 95/118 |
| Thunder and Lighting Ballistic Voltage-resisting Time | kV | 60/70, 75/85, 185/215 |
| Parameter | Unit | Value |
|---|---|---|
| Rated Voltage | V | 380, 220 |
| Rated Current Of Major Return Circuit | A | 100-3200 |
| Rated short-circuit Current-resisting | kA | 15, 30, 50 |
- Consultation & Design: We respond within 1 hour, provide recommendations and quotations. Technical drawings are confirmed within 7 days after payment.
- Production & Quality Control: Strict material screening, production with QC and test reports. Special accessories available upon request.
- Installation & Support: Professional installation guidance with on-site support available. Over 2 years warranty service.
- 30+ senior engineers offering 24/7 support with 30-minute response time
- 100,000m² factory with 250 workers and 4 production lines
- 15 years experience in power transformer design and production
- Compliance with GB 20052-2024/ANSI/IEEE/DOE2016/CSA/IEC60076 standards
- Global on-site technical support
-
500kVA Compact Substation Transformer Electric Voltage Transformer With Flyback Topology
500kVA Compact Substation Transformer Electric Voltage Transformer With Flyback Topology Product Specifications Attribute Value Type power transformer, distribution transformer, European Box-Type Substation Material Aluminum, Copper, Copper Winding Frequency 50Hz, 60Hz Shape flat, Rectangle Topology Flyback, Boost, BUCK, FORWARD Winding Material Copper, Aluminum Application Power Phase Three Coil Structure TOROIDAL Coil Number Multi-winding coil Input Voltage 380V, 180V, 115V
-
1500kVA Compact Substation Voltage Transformer 3 Phase Ground Mounted Transformer
1500kVA Compact Substation Voltage Transformer 3 Phase Ground Mounted Transformer Product Specifications Attribute Value Type Power transformer, distribution transformer, Auto Transformer Frequency 50Hz, 60Hz Winding Material Aluminum Application Power Distribution System Phase Three Coil Structure Layered Winding Input Voltage 3kV, 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 220kV, 400kV, 115kV, 132kV Output Voltage 5V, 400V, 208V, 200V, 415V, 127V, 11kV, 12V, 24V, 48V, 110V, 220V,
-
Box Type Compact Substation 500kva 630kva 800kva Outdoor Power Transformer
Box Type Compact Substation 500kva 630kva 800kva Outdoor Power Transformer Product Specifications Attribute Value Type Power transformer, distribution transformer Material Aluminum, Copper Frequency 50Hz, 60Hz Input Voltage 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 115kV Output Voltage 415V, 127V, 200V, 208V, 400V, 380V, 220V, 110V, 480V Capacity 500-2000 kVA Voltage Rating 11kV Power Rating 500kVA Insulation Class Class F Dimensions 1200mm x 800mm x 1000mm Cooling Method ONAN
