35kv 10kv Oil Immersed Electrical Transformer 1000kva 2500 Kva High Performance

high performance oil immersed transformer

high performance oil immersed electrical transformer

50hz oil immersed transformer

Place of Origin:

Jiangsu, China

Brand Name:

HENTG Power

Certification:

Model Number:

S22

Chat Now

Request A Quote

Product Details

Frequency:

50Hz, 60Hz, 50/60Hz

Phase:

Three

Coil Number:

Single Winding

Application:

Distribution System

Coil Structure:

Shell-Type Coil, Layer Coil, Fully Sealed Construction, Disc Coil, Round Coil

Output Voltage:

415V, 10kV, 110V, 220V, 380V, 400V , 440V

Input Voltage:

10.5kV, 3kV, 12.47kV, 6.6kV, 6.3kV, 6kV, 10kV, 35kV

Type:

Field Adjustable Transformer, AUTOTRANSFORMER, Voltage Regulator Transformer, Isolation Transformer, Oil-Immersed Transformer, Dual Winding Transformer, Oil-Immersed Transformer

Product Name:

Three Phase Oil Immersed Transformer

Highlight:

high performance oil immersed transformer

high performance oil immersed electrical transformer

50hz oil immersed transformer

Payment & Shipping Terms

Minimum Order Quantity

2 sets

Price

CN¥18,518.50-20,655.25/sets

Electric Step Down Power Transformer MV HV Oil Immersed Distribution Transformer 500kva 1000Kva

Chat Now

Video

3 Phase Step up Transformer 1250 Kva Industrial Electricity on Load Transformer Medium Voltage High Frequency Transformers

Chat Now

Video

HENTG Electric Power Transformer 400kVA 1000kVA Oil Immersed Energy Efficient

Chat Now

Video

Adjustable Voltage Oil Immersed Transformer 6.3-20KV 250-630kVA 3 Phase Multi Winding

Chat Now

+86 15074989773

info@hentgpower.com

Chat Now

Product Description

35kV/10kV Oil Immersed Electrical Transformer 1000kVA/2500kVA High Performance

Product Attributes

Attribute	Value
Frequency	50Hz, 60Hz, 50/60Hz
Phase	Three
Coil Number	Single Winding
Application	Distribution System
Coil Structure	Shell-Type Coil, layer coil, fully sealed construction, Disc Coil, round coil
Output Voltage	415V, 10kV, 110V, 220V, 380V, 400V, 440V
Input Voltage	10.5kV, 3kV, 12.47kV, 6.6kV, 6.3kV, 6kV, 10kV, 35kV
Type	Field Adjustable Transformer, AUTOTRANSFORMER, Voltage Regulator Transformer, Isolation Transformer, Oil-Immersed Transformer, Dual Winding Transformer
Product Name	Three Phase Oil Immersed Transformer

Technical Specifications

Main Product Parameters of S22 10KV Double Winding Series

Rated Capacity (KVA)	Vector Group	Voltage Combination	No-load Loss	Load Loss	Impedance
30	Yyn0 / Dyn11	10 6.3 6 ±5% ±2X2.5% 0.4	65	455	4.0
50			80	655
63			90	785
80			105	945
100			120	1140
125			135	1360
160			160	1665
200			190	1970
250			230	2300
315			270	2760
400			330	3250	4.5
500			385	3900
630			460	4460
800			560	5400
1000			665	7415
1250			780	8640
1600	940	10440	5.0
2000	1085	13180
2500	1280	13360

Application Fields

Municipal Distribution Network
Industrial Parks
Wind & Solar Power Systems
Commercial Buildings & Residential Areas
Rail Transit & Port Facilities

Why Choose Us?

Own Factory, Direct Manufacturer
24h Quick Quotation
Customization Available
Over 60 Countries Exported
Engineering Support Available

Frequently Asked Questions

Q: Who are we?

HENTG POWER is a professional designer, manufacturer and installer of power system solutions around the World, founded in 2011, occupying 100,000 square meters. We specialize in reliable, high-performance solutions for global power systems.

Q: How can we guarantee quality?

We always provide a pre-production sample before mass production and conduct final inspection before shipment, including QC & test reports. We accept FAT (Factory Acceptance Test). Our factory can manufacture oil type and dry type distribution transformers, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standards. We provide a guarantee service of over 2 years.

Q: Why choose us?

We have a professional and independent drawing team and technical team. We can confirm all contents on drawings with you within 7 days. Our professional technical team includes 30+ senior engineers offering 24-hour online service with responses within 30 minutes.

Q: What services can we provide?

We accept OEM, and business payment terms are negotiable.
